LY2NJ JQX-13F Small Intermediate Relay AC220V DC24V DC12V LY2N-J 8 Pin PCB Mount 10A Coil Power Fiberglass Base Control Relay for Industrial Automation Switching Applications
LY2NJ JQX-13F Small Intermediate Relay AC220V DC24V DC12V LY2N-J 8 Pin PCB Mount 10A Coil Power Fiberglass Base Control Relay for Industrial Automation Switching Applications
LY2NJ JQX-13F Small Intermediate Relay with 10A Coil Power for AC220V DC24V DC12V Systems
This small intermediate relay offers a dependable switching solution for industrial control panels, automation systems, and electronic projects. With support for AC220V, DC24V, and DC12V rated voltages, it adapts to a range of circuit requirements. The 8-pin design with a fiberglass base ensures secure mounting and reliable insulation. Its compact footprint makes it suitable for crowded PCBs where space is at a premium. Whether you are upgrading existing equipment or building new control circuits, this relay provides a consistent performance for on-off switching tasks.
Features and Construction
This relay is built around a simple yet effective design for intermediate duty applications. The key specifications are clearly defined for straightforward integration into your system.
Material and Build
The relay uses a fiberglass base which offers good electrical insulation and mechanical stability. The body is constructed to withstand typical industrial environments, though exact material grades are not specified. The 8-pin layout follows industry-standard spacing for easy PCB insertion.
Size and Practical Fit
Exact dimensions are not provided, but the form factor is described as 'small intermediate,' suggesting a compact size suitable for mounting alongside other components on a PCB. The 8-pin configuration is common for relays of this class, allowing straightforward replacement in existing sockets or direct soldering.
Uses and Placement
This relay is intended for switching electrical loads in control circuits. Its multiple voltage coil options expand its usability across different systems.
Industrial Automation
Integrate this relay into PLC output modules, motor control centres, or conveyor belt logic circuits. Its 10A coil power rating suits intermediate control tasks where lower-power relays are insufficient but heavy-duty contactors are unnecessary.
Power Supply Switching
Use this relay to switch AC or DC loads in power supply units, battery management systems, or HVAC controllers. The AC220V coil version is particularly common for mains-powered equipment, while DC24V/12V versions integrate easily with battery-powered or low-voltage control boards.
Benefits and Buying Value
This relay delivers straightforward value through its defined specifications and versatile voltage choices. No performance claims beyond the stated ratings are supported.
Reuse and Low Maintenance
As a solid-state switching component, this relay has no moving parts other than the internal armature. With proper use within rated limits, it offers a long operational life without routine maintenance. Replacement is simple due to the standard pin layout.
Why Choose This Product
The main advantage is the combination of multiple coil voltages (AC220V, DC24V, DC12V) in a single product line, letting you standardise on one relay type across different circuits. The 10A rating and 8-pin fiberglass base provide reliable electrical isolation and consistent switching performance for intermediate control applications.
